Specification information

 Material:galvanized sheet

wall thickness T:0.8 mm

Unit weight of the chute: 0.935kg/m

Packaging quantity: 4pcs per package

Material of wheels: PP/ESD

 Wheel color: black/white/yellow

 Maximum load-bearing capacity: 150kg/m

 Packaging requirements: Double-layer PVC plastic bags

 Features/Advantages

（1） The blocking function: The main function of the side plates of the sheet metal roller track is to prevent the goods from deviating during transportation, which could cause the goods to fall off or change their movement trajectory. The side plates of the wheels can play a guiding, blocking and preventive role.

（2）Cost advantage: As the raw material of sheet metal roller track is galvanized sheet and the processing technology is simple, it has a cost advantage.

（3）The sheet metal roller track adopts a hollow and irregular-shaped bending structure, which not only reduces weight but also enhances bending resistance, making it suitable for long-span installation

（4）The sheet metal roller track is made of galvanized sheet metal, and its surface is treated with galvanization to prevent rust.

 Applications

（1）Gravity sliding rack: The flow bars can be installed on the gravity sliding rack, and the goods can slide by their own weight

（2）Guide rail system: In the guide rail system, the flow strips can guide the goods to move along th predetermined path, ensuring the smooth transportation of goods.

（3）Production line: Flow strips can be used to connect different workstations to achieve continuous material transportation.

（4）Logistics equipment: Flow strips are used in various logistics equipment, such as turnover carts, logistics trolleys, etc.

（5）Warehouse management: The roller track helps optimize the utilization of warehouse space. Through the design of a three-dimensional structure, it increases the storage capacity of the warehouse and the convenience of access.

（6）Dust-free workshop: Roller track can be used to build material handling systems that meet cleanliness requirements, reducing the generation and diffusion of dust.

（7） Large supermarkets: Roller track can be applied to the storage and display systems of goods, improving the efficiency of goods circulation.
